PacDrive 3 Training (including 'SoMachine Motion')
Proud to be the ONLY UK based firm offering PacDrive 3 training.
Our training programs are designed to ensure you get an immediate return on your investment. Additionally, we aim to help you reduce dependency on your suppliers and to this end, we have designed a Two Module program to ensure there is something for everyone, no matter your level of PacDrive 3 experience.
PacDrive 3 - Module 1
After the completion of Module 1, you will be able to quickly diagnose and clear errors on machines with hardware. This training module is based on PacDrive3 Service Tools and PacDrive3 Documentation.
- Introduction to PacDrive3
- First look at PacDrive 3
- Hardware overview
- Dive into PacDrive3 system
- Communication with PacDrive3
- Motors & Motion
- First look at servomotors
- Position control
- Diagnosis Messages
- Diag Codes
- Diagnosis on motors and controllers
- Substitute motors, drives and controllers
- Safety Wiring
- Inverter enable circuit / EMC
PacDrive 3 - Module 2
Module 2 is based on SoMachine Motion SoMM and provides an introduction on how to diagnose and clear application specific errors in a project structure.
- Introduction to SoMachine Motion
- Getting connected with the controller
- SoMM User Interface
- SoMM Device Tree, watch and trace
- Activating drives and Position control
- Monitoring and Trace recording
- Advanced Troubleshooting
- Basic Motion using Positioning Instructions within a user program
